Fluke 990DSL - Ping Connection Type Setups

XDSL Testing and Loop Qualification
Ping
5
5-25
Table 5-3. Ping Connection Type Setups
Connection Type Setup Parameters
PPPoE User ID: Enter a valid User ID for the line under test.
Password: Enter a valid password associated with the
above User ID.
VPI: Enter the VPI (default = 0, commonly used), which
may vary according to the standards developed for a
particular carrier’s network.
VCI: Enter the VCI (default = 35, commonly used),
which may vary according to the standards developed
for a particular carrier’s network.
ATM Enc.: Select either LLC/SNAP (default,
commonly used) or VCMUX (utilized by some ATM
networks) for the ATM Encapsulation field.
PPPoE/Static IP Note: This connection type is provided for users
(usually businesses) who have requested a Static IP
address, and the service is provided with PPPoE.
User ID: Enter a valid User ID for the line under test.
Password: Enter a valid password associated with the
above User ID.
Static IP: Enter the static IP address that has been
assigned to the customer.
Subnet Mask: Enter the subnet mask address
associated with the above static IP address.
Gateway: Enter the gateway address associated with
the above static IP address and line under test.
DNS Server 1: Enter the DNS Server 1 address
associated with the above static IP address.
DNS Server 2: Enter the DNS Server 2 address
associated with the above static IP address.
