Restore
Defaults
Facility Cable No. - NPG5804
Pair / Terminal No. - 1001
CopperPro Pair No. - 1
Term. Impedance - 600 Ohms
Measurement Filter - C-Message
Nm Pass Thresh. - ≤ 20 dBrn
PI Pass Thresh. - ≤ 80 dBrn
Setups - VF Noise
Edit
acy07s.eps
Figure 3-3. Typical Setup Menu
Beneath the generic setup parameters is a second group of setup parameters.
The parameters in this group are specific to the selected test. Look at the
Setup-VF Noise screen, which is shown in Figure 3-3. The four parameters on
the bottom of the screen apply to the VF Noise test only. For descriptions of
the setup parameters for a particular test, refer to the table in the setup section
for that test.
