7 Problem Solving
230
Problem Solving
7
1 Make sure that the machine is not operating,
and open the front cover.
2 Turn green lever 2 at the center of the
transfer module to the right until it is in the
horizontal position (1), and then pull the
transfer module towards you until it stops (2).
3 Remove any jammed paper that is visible.
Note • If the paper is torn, make sure no piece of
paper remains inside the machine.
4 Remove the jammed paper while pulling
lever 2a to the right.
5 Pull down lever 2b (1), and remove the
jammed paper (2).
6 Return levers 2a and 2b to their original positions.
To Next Page
