Paper and Other Media
2
Changing the Paper Size for Tray 6 (A4 High Capacity Feeder)
The following describes how to change paper size in Tray 6 (A4 High Capacity Feeder).
1 Pull out the tray until it stops.
Important • While the machine is processing a job, do
not pull out the tray that is being used for
job.
• To prevent paper jams or erroneous detection of loaded paper in a tray by the machine, do
not add paper on top of any remaining paper in the tray. Remove any paper remaining in the
tray and then load the paper on newly loaded paper.
2 Remove any paper loaded in the tray.
3 Open the end guide (1) and unscrew the
screw (2). Then remove the guide from the
tray.
4 Insert the small protrusions at the bottom of the guide into the holes corresponding to
the paper size (1). Then insert the screw into a hole corresponding to the paper size
on top of the guide and tighten the screw (2).
5 Unscrew the screw of the front guide and
remove the guide from the tray.
Be sure to pull out the paper tray slowly. If
pulled out with too much force, the tray
may hit and injure your knees or other
parts of your body.
