Stapler Faults
261
Problem Solving
7
Staple Jams in Staple Cartridge (For Finisher C2 or Finisher C2 with
Booklet Maker)
The following describes how to clear staple jams occurring in the staple cartridge of the
Finisher C2 (optional) or the Finisher C2 with Booklet Maker (optional).
The following example shows how to clear a staple jam that occurred in the Finisher C2
with Booklet Maker. The procedure for the Finisher C2 is the same.
1 Make sure that the machine is not operating,
and open the finisher front cover.
2 Grip lever R1 of the staple cartridge holder,
and pull out the holder to the right towards
you.
3 Remove the staple cartridge holder by
gripping the orange lever.
Note • The staple cartridge is firmly set in place.
Removing the cartridge may require
pulling on the cartridge with slight force.
4 After you take out the staple cartridge, check
inside of the finisher for any remaining
staples.
To Next Page
