7 Problem Solving
242
Problem Solving
7
Paper Jams at Lever 4b (For Finisher C2 with Booklet Maker)
1 Open the front cover of the finisher.
2 Pull lever 4b to the left.
3 Remove any jammed paper.
4 Pull out unit 4.
5 Remove all jammed paper protruding from
the top left of the unit and all the paper inside
the unit.
Note • If the paper is torn, make sure no piece of
paper remains inside the machine.
6 Return unit 4 to its original position.
7 Close lever 4b.
8 Close the front cover of the finisher.
Note • A message will be displayed and the machine will not operate if the front cover of the finisher
is even slightly open.
To Next Page
