Stapler Faults
263
Problem Solving
7
2 While pressing the lever for R2 R3 to the
right (1), pull the staple cartridge unit out of
the machine (2).
3 Hold the booklet staple cartridge by the tabs
on both sides and lift the cartridge out of the
unit.
4 Remove the jammed staples as shown in the
illustration.
5 While holding the tabs of the removed
booklet staple cartridge, push the cartridge
back to its original position. Lightly push the
cartridge down until you hear it click into
place.
6 Push the removed unit back into the
machine until it clicks into place.
7 Close the finisher front cover.
Note • A message will be displayed and the machine will not operate if the front cover of the finisher
is even slightly open.
If you cannot remove jammed staples even after you perform the above procedure,
contact your local Fuji Xerox representative.
