Replacing Consumables
71
Maintenance
3
2 While pushing the lever for R2 R3 to the right
(1), pull the staple cartridge unit out of the
machine (2).
3 Hold the staple cartridge by the tabs on both
sides and lift the cartridge out of the unit.
4 While holding the tabs of the new staple
cartridge, push the cartridge into the unit.
Lightly push the cartridge down until you
hear it click into place.
5 Push the staple cartridge unit into its original
position.
6 Close the right cover of the finisher.
Note • A message will be displayed and the machine will not operate if the right cover of the finisher
is even slightly open.
