Fujitsu PRIMERGY TX1310 M3

TX1310 M3 Upgrade and Maintenance Manual 109
Expansion cards and backup units
Expansion card overview
Figure 52: Expansion card overview
I For the latest information of the installing order, refer to your server’s
hardware configurator available online at the following address:
http://ts.fujitsu.com/products/standard_servers/index.html
For Japan:
http://jp.fujitsu.com/platform/server/primergy/system/
Adapter Class
Category
Adapter
Installation
Sequence
Adapter
Vendor Adapter Product Name
Max #
Adapter 123 4
Controller Card
–
Graphic
1
NVIDIA
NVIDIA NVS 315 PCI-E x16, 1GB,
Dual-DVI-I or Dual VGA
1- - - 1
2
Fujitsu VGA extension card 1- -1 -
Controller Card -
L
AN
1
Intel
PLAN AP 1x1Gbit Cu Intel I210-T1
(
Beaver Lake)
2 1 2 3 4
2
Intel
PLAN CP 2x1Gbit Cu Intel I350-T2
(
Stonylake-DP)
1- -1 2
