116 Upgrade and Maintenance Manual TX1310 M3
Expansion cards and backup units
9.3.1.4 Concluding steps
Ê "Reassembling" on page 51
Ê If applicable, connect external cables to the expansion card.
Ê "Connecting the power cord" on page 56
Ê "Switching on the server" on page 57
Ê If applicable, "Enabling Option ROM scan" on page 65
Ê "Resuming BitLocker functionality" on page 70
Ê If applicable, "After replacing/upgrading LAN controllers" on page 73
9.3.2 Removing expansion cards
9.3.2.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 61
Ê "Shutting down the server" on page 44
Ê "Disconnecting the power cord" on page 45
Ê If applicable, disconnect all external cables from the expansion card.
Ê "Getting access to the component" on page 46
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Only for removing slot brackets:
– Phillips PH2 / (+) No. 2 screw driver
– Hexagon nut 5 mm (for hexagon bolt)
