TX1310 M3 Upgrade and Maintenance Manual 157
12.2 Optical disk drive (ODD)
12.2.1 Installing an ODD
12.2.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 61
Ê "Shutting down the server" on page 44
Ê "Disconnecting the power cord" on page 45
Ê "Getting access to the component" on page 46
12.2.1.2 Removing the dummy cover bay 1
If bay 1 is to be equipped, it is necessary to remove its dummy cover from the
front cover.
Ê Remove the front cover, see section "Removing the front cover" on page 50.
Figure 89: Removing the dummy cover bay 1
Ê Push the dummy cover out of bay 1 from the rear side of the front cover.
Ê Install the front cover, see section "Installing the front cover" on page 51.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: tool-less
