Fujitsu PRIMERGY TX1310 M3 - Installing the PSU

TX1310 M3 Upgrade and Maintenance Manual 79
Power supply unit (PSU)
6.2.3 Installing the PSU
Figure 27: Inserting the PSU
Ê Insert the PSU into the chassis in a slight angle (1) and position it in place
(2).
Ê Slide the PSU towards the rear of the chassis as far as it will go (3).
