214 Upgrade and Maintenance Manual TX1310 M3
16.3 Replacing cables
I The following steps are only required in case of a defective cable.
16.3.1 Replacing the system cable (accessible drives /
top HDD cage)
16.3.1.1 Preliminary steps
Ê "Shutting down the server" on page 44
Ê "Disconnecting the power cord" on page 45
Ê "Getting access to the component" on page 46
16.3.1.2 Removing the defective system cable
Ê "Removing the PSU" on page 76
Ê "Removing an ODD" on page 160
Ê If applicable, remove HDD3 and HDD4, see section "Removing a 3.5-inch
HDD" on page 90.
Ê Push the backup drive somewhat to the front to get more space, see section
"Removing a backup drive" on page 169.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tool: tool-less
