TX1310 M3 Upgrade and Maintenance Manual 205
16 Cables
16.1 Overview cables
No. Part number Description From - to
Basic
C1 T26139-Y4023-V203 HDD cable
System board to HDD1 and HDD2
(power and data)
C2 T26139-Y4023-V205 Power / SATA 2 cable
System board to HDD3, HDD4
and ODD (power and data),
System board to RDX (only
power)
Optional
C3 T26139-Y4018-V500 USB 3.0 cable System board to RDX (data)
C4 T26139-Y3589-V411 Serial cable System board to serial connector
