Fujitsu PRIMERGY TX1310 M3

178 Upgrade and Maintenance Manual TX1310 M3
Serial connector
14.2 Removing the serial connector
14.2.1 Preliminary steps
Ê "Shutting down the server" on page 44
Ê "Disconnecting the power cord" on page 45
Ê "Getting access to the component" on page 46
Ê "Removing the air deflector" on page 58
14.2.2 Removing the serial connector
Figure 109: Removing the serial connector (A)
Ê Remove the two hexagon bolts.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tool: Hexagon screw driver 5 mm
