224 Upgrade and Maintenance Manual TX1310 M3
Appendix
17.2 Connectors and indicators
17.2.1 Connectors on the system board
Figure 143: Internal connectors of system board D3521
12 CPU / CPU heat sink / CPU fan
13 System board
Pos. Component
