Fujitsu PRIMERGY TX1310 M3

TX1310 M3 Upgrade and Maintenance Manual 225
Appendix
No. Print Description
1 Fan (OEM) Rear fan connector
2 PWR 12V PSU Power
3 Fan (CPU) CPU fan connector
4 SATA PWR SATA Power connector
5 FP Front panel connector
6 USB 3.0 USB 3.0 connector
7 SATA 3 SATA 3 connector
8 USB 3/4 USB connector for backup drives
9 SATA 5 SATA 5 connector
10 SATA 4 SATA 4 connector
11 SATA PWR SATA power connector
12 SATA 1 SATA 1 connector
13 SATA 2 SATA 2 connector
14 USB 9_1 USB 2.0 connector
15 Fan (SYS) Front fan connector
16 TPM Connector for TPM module
17 LAN/USB 3.0 LAN / USB 3.0 connector
18 USB 3.0 USB 3.0 connector
19 COM1 Connector for Serial port (optional)
20 DP1.2 DisplayPort (VGA) connector
21 USB USB 2.0 connector
