Serial connector
14.3 Replacing the serial connector
14.3.1 Preliminary steps
Ê "Shutting down the server" on page 44
Ê "Disconnecting the power cord" on page 45
Ê "Getting access to the component" on page 46
Ê "Removing the air deflector" on page 58
14.3.2 Removing the serial connector
Ê Remove the serial connector, see section "Removing the serial connector"
on page 178.
14.3.3 Installing the serial connector
Ê Install the serial connector, see section "Installing the serial connector" on
page 176.
14.3.4 Concluding steps
Ê "Installing the air deflector" on page 59
Ê "Reassembling" on page 51
Ê "Connecting the power cord" on page 56
Ê "Switching on the server" on page 57
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tool: Hexagon screw driver 5 mm
