Fujitsu PRIMERGY TX1310 M3

TX1310 M3 Upgrade and Maintenance Manual 185
System board and components
15.3 Trusted Platform Module (TPM)
There are different TPM kits available. The procedures of installing, removing
and replacing are identic.
Figure 112: TPM installation kit - example 1
Figure 113: TPM installation kit - example 2
1 TPM (Trusted Platform Module) 3 Special screw for TPM
2 TPM spacer
I The black TPM spacer is
not used in this server.
4 TPM bit insert for TPM special
screw
/
0
1
2
