TX1310 M3 Upgrade and Maintenance Manual 161
12.2.2.3 Concluding steps
Ê Remove the fixation plates from the removed accessible drives.
Ê Secure the fixation plates in the chassis.
Ê "Reassembling" on page 51
Ê "Connecting the power cord" on page 56
Ê "Switching on the server" on page 57
Ê "Reconfiguring the backup software solution" on page 66
Ê "Resuming BitLocker functionality" on page 70
12.2.3 Replacing an ODD
12.2.3.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 61
Ê "Removing backup and optical disk media" on page 63
Ê "Verifying and configuring the backup software solution" on page 63
Ê "Shutting down the server" on page 44
Ê "Disconnecting the power cord" on page 45
Ê "Getting access to the component" on page 46
12.2.3.2 Replacing an ODD
Ê Remove the defective ODD, see section "Removing an ODD" on page 160.
Ê Remove the fixation plate from the left side of the defective ODD.
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: tool-less
