96 Upgrade and Maintenance Manual TX1310 M3
8.1 Basic information
V CAUTION!
Since the system fans are not redundant they have to be replaced
immediately in case of defects or pre-failure events.
Figure 40: Positions of the system fans
I The CPU fan is implemented in the heat sink. When the CPU fan is
defective, the heat sink must be replaced, see section "Replacing the
heat sink" on page 147.
1 Rear fan (Fan OEM)
2 CPU fan (implemented in the heat sink)
3 Front fan (Fan SYS)
