Fujitsu PRIMERGY TX1310 M3

140 Upgrade and Maintenance Manual TX1310 M3
Processor (CPU)
Figure 74: Closing the load plate (B)
Ê Lower the socket lever while making sure that the front edge of the load plate
slides under the shoulder screw cap (see close-up) as the lever is lowered.
Figure 75: Closing the socket release lever
Ê Latch the socket lever under the load plate tab.
