Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin
190-02954-01 Rev. A
Appendix
279
Flight
Instruments EIS
Nav/Com/
XPDR/Audio
Flight
Management
Hazard
Avoidance AFCS
Additional
Features Annun/Alerts Appendix Index
Flight
Instruments EAS
Audio and
CNS
Flight
Management
Hazard
Avoidance AFCS
Additional
Features
Abnormal
Operation Annun/Alerts Appendix Index
Level 1 Level 2 Level 3 Level 4 Level 5 Description
Pathways Displays Pathway boxes on the
synthetic vision display.
Wire Displays power lines on the synthetic
vision display.
SVT Airports Displays Airport Signs softkey
Runway
Locator
Displays cyan chevrons and cyan mile
markers which extend 10 nm from
the programmed runway.
Airport
Signs
Displays position markers for airports
within approximately 15 nm of the
current aircraft position. Airport
identifiers are included when the
airport is within approximately 9 nm.
Altitude
Instruments
Displays the softkeys for enabling or
disabling Synthetic Vision Technology
(SVT) features.
Horizon
Heading
Displays Pathway boxes on the SVT
display.
PFD
Mode
Enables or disables a Display Pane
to the right or left (depending on
pilot-side or copilot-side) on the PFD
/ PFW:
FULL: Display Pane is disabled. The
PFD / PFW display occupies the full
screen.
Split: Display Pane is enabled. The
PFD / PFW screen is split between
the PFD / PFW display and the
Display Pane.
Bearing 1 Cycles the Bearing 1 Information
Window through NAV1, NAV2, GPS,
ADF1, and Off.
Bearing 2 Cycles the Bearing 2 Information
Window through NAV1, NAV2, GPS,
ADF1, and Off.
