Level 1 Level 2 Level 3 Level 4 Level 5 Description
Other
PFD
Settings
Displays additional PFD / PFW
settings softkeys.
Wind Displays the wind option softkeys.
→DEG KT Total wind direction arrow with
digital numeric direction and speed.
↑→KT Headwind/tailwind and crosswind
arrows with numeric speed
components.
Off Wind information not displayed.
AOA Selects the display mode for the
Angle of Attack (AOA) Indicator on
the PFD / PFW:
Auto: Selects AOA ‘Auto’ mode. (See
Flight Instruments section)
On: Displays AOA Indicator on the
PFD / PFW.
Off: Removes AOA Indicator from the
PFD / PFW.
Altitude
Units
Displays softkeys to select altitude
unit parameters.
Meters Displays altimeter overlay in meters.
IN Displays the BARO setting as inches
of mercury.
HPA Displays the BARO setting as
hectopascals.
Sensors Displays the sensor selection softkeys.
ADC
Settings
Displays the ADC selection softkeys.
ADC 1 Selects the number 1 ADC. The
softkey annunciator is green when
selected.
ADC 2 Selects the number 2 ADC. The
softkey annunciator is green when
selected.
