Level 1 Level 2 Level 3 Level 4 Level 5 Description
AHRS
Settings
Displays the AHRS selection softkeys.
AHRS 1 Selects the number 1 AHRS. The
softkey annunciator is green when
selected.
AHRS 2 Selects the number 2 AHRS. The
softkey annunciator is green when
selected.
OBS Selects OBS mode on the CDI when
navigating by GPS (only available
with active leg). When OBS is on, the
softkey annunciator is green. ‘SUSP’
will replace ‘OBS’ when waypoint
sequencing is suspended.
Active
NAV
Cycles through GPS, NAV1, and
NAV2 navigation modes on the CDI.
PFD Map
Settings
Displays HSI Map settings softkeys
(the Inset Map is not available when
PFD / PFW is in Split Mode).
HSI Map
Layout
Displays softkeys used to select HSI
Map layouts.
Map Off Removes the PFD Map from the
display.
HSI Map Displays the HSI Map.
HSI Traffic
Overlays a dedicated traffic
display on the HSI.
Map
Range -
Decreases the HSI Map display range
(only available if HSI Map is enabled).
Map
Range +
Increases the HSI Map display range
(only available if HSI Map is enabled).
Map
Overlays
Displays HSI Map overlay softkeys
(only available if HSI Map is enabled).
Terrain
Settings
Selects the display of terrain
information on the HSI Map:
