Programmable Logic
P74x/EN PL/N
a7
MiCOM P74
1, P742, P743
(PL) 7-
17
PL
Relay
DDB
No.
English Text Type Source Description
P741
469
Battery Fail
PSL Input Signal
Relay Integrity
Front panel Battery Failure
P741
470
Field Voltage Fail
PSL Input Signal
Relay Integrity
48V Field Voltage Failure
P741
471
Comm2 H/W
FAIL
PSL Input Signal
Second rear port
Second rear port Alarm
P741
472
GOOSE IED
Absent
PSL Input Signal
IEC 61850
The IED is not subscribed to a publishing IED in
the current scheme
P741
473
NIC Not Fitted
PSL Input Signal
IEC 61850
Ethernet board not fitted
P741
474
NIC No
Response
PSL Input Signal
IEC 61850
Ethernet board not responding
P741
475
NIC Fatal Error
PSL Input Signal
IEC 61850
Ethernet board unrecoverable error
P741
476
NIC Soft. Reload
PSL Input Signal
IEC 61850
Ethernet card software reload Alarm
P741
477
Bad TCP/IP Cfg.
PSL Input Signal
IEC 61850
Bad TCP/IP configuration alarm
P741
478
Bad OSI Config.
PSL Input Signal
IEC 61850
Bad OSI configuration alarm
P741
479
NIC Link Fail
PSL Input Signal
IEC 61850
Ethernet link lost
P741
480
NIC SW Mis-
Match
PSL Input Signal
IEC 61850
Ethernet board software not compatible with
main CPU
P741
481
IP Addr Conflict
PSL Input Signal
IEC 61850
The IP address of the IED is already used by
another IED
P741
482
IM Loopback
PSL Input Signal
InterMiCOM
InterMiCOM indication that Loopback testing is
in progress
P741
483
IM Message Fail
PSL Input Signal
InterMiCOM
InterMiCOM Message Failure Alarm
P741
484
IM Data CD Fail
PSL Input Signal
InterMiCOM
InterMiCOM Data Channel Detect Fail
P741
485
IM Channel Fail
PSL Input Signal
InterMiCOM
InterMiCOM Channel Failure Alarm
P741
486
Backup Setting
PSL Input Signal
InterMiCOM
Backup setting Alarm
This is an alarm that is ON if any setting fail
during the setting changing process. If this
happens, the relay will use the last known good
setting.
P741
512
Virtual Output 1
GOOSEOUT
PSL
GOOSE Output 1
Allows user to control a binary signal which can
be mapped via SCADA protocol output to other
devices
P741
543
Virtual Output 32
GOOSEOUT
PSL
GOOSE Output 32
Allows user to control a binary signal which can
be mapped via SCADA protocol output to other
devices
P741
584
InterMiCOM in 1
INTERIN
InterMiCOM
InterMiCOM IM1 Signal Input - is driven by a
message from the remote line end
P741
591
InterMiCOM in 8
INTERIN
InterMiCOM
InterMiCOM IM8 Signal Input - is driven by a
message from the remote line end
P741
592
InterMiCOM out
1
INTEROUT
InterMiCOM
InterMiCOM IM1 Signal Output - mapping what
will be sent to the remote line end
P741
599
InterMiCOM out
8
INTEROUT
InterMiCOM
InterMiCOM IM8 Signal Output - mapping what
will be sent to the remote line end
P741
608
Control Input 1
CONTROL
Control Input
Command
Control Input 1 - for SCADA and menu
commands into PSL
P741
639
Control Input 32
CONTROL
Control Input
Command
Control Input 32 - for SCADA and menu
commands into PSL
P741
640
LED 1 Red
TRI_LED
PSL (LED)
Programmable LED 1 Red is energized
P741
641
LED 1 Grn
TRI_LED
PSL (LED)
Programmable LED 1 Green is energized
P741
654
LED 8 Red
TRI_LED
PSL (LED)
Programmable LED 8 Red is energized
P741
655
LED 8 Grn
TRI_LED
PSL (LED)
Programmable LED 8 Green is energized
P741
656
FnKey LED 1
Red
TRI_LED
PSL (LED)
Programmable Function Key LED 1 Red is
energized
P741
657
FnKey LED 1
Grn
TRI_LED
PSL (LED)
Programmable Function Key LED 1 Green is
energized
P741
674
FnKey LED 10
Red
TRI_LED
PSL (LED)
Programmable Function Key LED 10 Red is
energized
