GE P742

P74
x/EN PL/Na7
Programmable Logic
(PL)
7-
18
MiCOM P74
1, P742, P743
PL
Relay
DDB
No.
English Text Type Source Description
P741
675
FnKey LED 10
Grn
TRI_LED
PSL (LED)
Programmable Function Key LED 10 Green is
energized
P741
676
Function Key 1
FUNCTION_KEY
PSL (Function Key)
Function Key 1 is activated. In ‘Normal’ mode it
is high on key press and in ‘Toggle’ mode
remains high/low on single key press
P741
685
Function Key 10
FUNCTION_KEY
PSL (Function Key)
Function Key 10 is activated. In ‘Normal’ mode it
is high on key press and in ‘Toggle’ mode
remains high/low on single key press
P741
700
Relay condit 01
OUTPUT_CON
Output Conditioner
Input to Relay Output Conditioner
P741
707
Relay condit 08
OUTPUT_CON
Output Conditioner
Input to Relay Output Conditioner
P741
764
LED 1 Red
Condit
TRI_LED_CON
Output Conditioner
Assignment of input signal to drive output LED
1Red
P741
765
LED 1 Grn
Condit
TRI_LED_CON
Output Conditioner
Assignment of signal to drive output LED
1Green.
To drive LED1 Yellow DDB 764 and DDB 765
must be driven at the same time
P741
778
LED 8 Red
Condit
TRI_LED_CON
Output Conditioner
Assignment of signal to drive output LED 8Red
P741
779
LED 8 Grn
Condit
TRI_LED_CON
Output Conditioner
Assignment of signal to drive output LED 8
Green.
To drive LED8 Yellow DDB 778 and DDB 779
must be active at the same time
P741
780
FnKey LED 1
Red
TRI_LED_CON
Output Conditioner
Assignment of signal to drive output Function
Key LED 1 Red.
This LED is associated with Function Key 1
P741
781
FnKey LED 1
Grn
TRI_LED_CON
Output Conditioner
Assignment of signal to drive output Function
Key LED 1 Green.
This LED is associated with Function Key 1.
To drive function key LED, yellow DDB 692 and
DDB 693 must be active at the same time
P741
797
FnKey LED 9
Grn
TRI_LED_CON
Output Conditioner
P741
798
FnKey LED 10
Red
TRI_LED_CON
Output Conditioner
Assignment of signal to drive output Function
Key LED 10 Red.
This LED is associated with Function Key 10
P741
799
FnKey LED 10
Grn
TRI_LED_CON
Output Conditioner
Assignment of signal to drive output Function
Key LED 10 Green.
This LED is associated with Function Key 10.
To drive function key LED1 yellow, DDB 710
and DDB 711 must be active at the same time
P741
923
Int. Node 923
Can be created automatically by the PSL
P741
1023
Int. Node 1023
Can be created automatically by the PSL
P741
1024
virtual input 1
GOOSEIN
GOOSE Input
Command
Virtual Input 1
Allows binary signals that are mapped to virtual
inputs to interface into PSL
P741
1087
virtual input 64
GOOSEIN
GOOSE Input
Command
Virtual Input 64
Allows binary signals that are mapped to virtual
inputs to interface into PSL
P741
1152
Quality VIP1
PSL Input Signal
PSL
Validation of the virtual input 1 (signal correct).
P741
1215
Quality VIP64
PSL Input Signal
PSL
Validation of the virtual input 64 (signal correct).
P741
1280
PubPres VIP 1
PSL Input Signal
PSL
Publishing presence of virtual input 1: indicates
virtual input 1 presence.
P741
1343
PubPres VIP 64
PSL Input Signal
PSL
Publishing presence of virtual input 64: indicates
virtual input 64 presence.
1.7.2 Sorted by DDB name:
Relay
DDB
No.
English Text Type Source Description
P741
271
87BB 3Ph
Blocked
PSL Input Signal
Scheme Integrity
87BB alarm blocked by opto input (or between
the 8 inputs “INP block 3ph” z1 to z8)
P741
392
87BB Blocked
PSL Input Signal
Scheme Integrity
87BB phase and earth algorithms blocked by
opto input
P741
367
87BB
DelayedTrip
PSL Input Signal
87BB Busbar
Protection
87BB Trip after fault detection on 2 successive
half periods. Function to be able to trip on
internal fault with CT saturation.
P741
385
87BB Enabled
PSL Input Signal
87BB Busbar
Protection
Busbar protection enable
P741
366
87BB InstantTrip
PSL Input Signal
87BB Busbar
Protection
87BB Trip after fault detection on 2 successive
samples. Function disabled during CT
saturation.
