GE P742

Programmable Logic
P74x/EN PL/N
a7
MiCOM P74
1, P742, P743
(PL) 7-
21
PL
Relay
DDB
No.
English Text Type Source Description
P741
224
INP Lck Lev.1 z8
PSL Output
Signal
PSL
(Commissioning)
Maintenance Mode 1 (87BB monitoring) of zone
8 opto input
P741
239
INP Lck Lev.2 z1
PSL Output
Signal
PSL
(Commissioning)
Maintenance Mode 2 (50BF & 87BB blocked) of
zone 1 opto input
P741
232
INP Lck Lev.2 z8
PSL Output
Signal
PSL
(Commissioning)
Maintenance Mode 2 (50BF & 87BB blocked) of
zone 8 opto input
P741
1023
Int. Node 1023
Can be created automatically by the PSL
P741
923
Int. Node 923
Can be created automatically by the PSL
P741
584
InterMiCOM in 1
INTERIN
InterMiCOM
InterMiCOM IM1 Signal Input - is driven by a
message from the remote line end
P741
591
InterMiCOM in 8
INTERIN
InterMiCOM
InterMiCOM IM8 Signal Input - is driven by a
message from the remote line end
P741
592
InterMiCOM out 1
INTEROUT
InterMiCOM
InterMiCOM IM1 Signal Output - mapping what
will be sent to the remote line end
P741
599
InterMiCOM out 8
INTEROUT
InterMiCOM
InterMiCOM IM8 Signal Output - mapping what
will be sent to the remote line end
P741
481
IP Addr Conflict
PSL Input Signal
IEC 61850
The IP address of the IED is already used by
another IED
P741
247
Lck Lev.1 Zone 1
PSL Input Signal
Scheme Integrity
Commissioning mode 1: 50BF disabled in zone
1
P741
240
Lck Lev.1 Zone 8
PSL Input Signal
Scheme Integrity
Commissioning mode 1: 50BF disabled in zone
8
P741
255
Lck Lev.2 Zone 1
PSL Input Signal
Scheme Integrity
Commissioning mode 2: 87BB & 50BF disabled
in zone 1
P741
248
Lck Lev.2 Zone 8
PSL Input Signal
Scheme Integrity
Commissioning mode 2: 87BB & 50BF disabled
in zone 8
P741
641
LED 1 Grn
TRI_LED
PSL (LED)
Programmable LED 1 Green is energized
P741
765
LED 1 Grn Condit
TRI_LED_CON
Output Conditioner
Assignment of signal to drive output LED
1Green.
To drive LED1 Yellow DDB 764 and DDB 765
must be driven at the same time
P741
640
LED 1 Red
TRI_LED
PSL (LED)
Programmable LED 1 Red is energized
P741
764
LED 1 Red
Condit
TRI_LED_CON
Output Conditioner
Assignment of input signal to drive output LED
1Red
P741
655
LED 8 Grn
TRI_LED
PSL (LED)
Programmable LED 8 Green is energized
P741
779
LED 8 Grn Condit
TRI_LED_CON
Output Conditioner
Assignment of signal to drive output LED 8
Green.
To drive LED8 Yellow DDB 778 and DDB 779
must be active at the same time
P741
654
LED 8 Red
TRI_LED
PSL (LED)
Programmable LED 8 Red is energized
P741
778
LED 8 Red
Condit
TRI_LED_CON
Output Conditioner
Assignment of signal to drive output LED 8Red
P741
267
Locking Level 1
PSL Input Signal
Scheme Integrity
Commissioning mode 1: 87BB monitoring
Logical OR of DDB 224 to 231
P741
268
Locking Level 2
PSL Input Signal
Scheme Integrity
Commissioning mode 2: 87BB & 50BF disabled
Logical OR of DDB 232 to 239
P741
199
Man.Trip Zone 1
PSL Input Signal
Commissioning
Manual trip of zone 1
P741
192
Man.Trip Zone 8
PSL Input Signal
Commissioning
Manual trip of zone 8
P741
389
Manual Start DR
PSL Input Signal
Commissioning
Disturbance recorder - Manual start
P741
355
Minor Err COM1
PSL Input Signal
Relay Integrity
Minor error in communication board A
P741
356
Minor Err COM2
PSL Input Signal
Relay Integrity
Minor error in communication board B
P741
357
Minor Err COM3
PSL Input Signal
Relay Integrity
Minor error in communication board C
P741
358
Minor Err COM4
PSL Input Signal
Relay Integrity
Minor error in communication board D
P741
359
Minor Err COM5
PSL Input Signal
Relay Integrity
Minor error in communication board E
P741
360
Minor Err COM6
PSL Input Signal
Relay Integrity
Minor error in communication board F
P741
361
Minor Err COM7
PSL Input Signal
Relay Integrity
Minor error in communication board G
P741
475
NIC Fatal Error
PSL Input Signal
IEC 61850
Ethernet board unrecoverable error
P741
479
NIC Link Fail
PSL Input Signal
IEC 61850
Ethernet link lost
P741
474
NIC No
Response
PSL Input Signal
IEC 61850
Ethernet board not responding
P741
473
NIC Not Fitted
PSL Input Signal
IEC 61850
Ethernet board not fitted
P741
395
NIC Read Only
PSL Output
Signal
PSL
All setting changes and most command/control
actions blocked for the Ethernet port (when
option available).
P741
476
NIC Soft. Reload
PSL Input Signal
IEC 61850
Ethernet card software reload Alarm
P741
480
NIC SW Mis-
Match
PSL Input Signal
IEC 61850
Ethernet board software not compatible with
main CPU
P741
64
Opto Label 01
OPTO
Opto Input
Opto Input 1
P741
71
Opto Label 08
OPTO
Opto Input
Opto Input 8
P741
351
PU Adr 07 error
PSL Input Signal
Scheme Integrity
Error: several PUs with address 7
P741
324
PU Adr 34 error
PSL Input Signal
Scheme Integrity
Error: several PUs with address 34
P741
286
PU Error Alm CZ
PSL Input Signal
Scheme Integrity
PU error Alarm in the Check Zone
P741
159
PU Error Alm z1
PSL Input Signal
Scheme Integrity
PU error alarm in zone 1
