P74
x/EN PL/Na7
Programmable Logic
(PL)
7-
22
MiCOM P74
1, P742, P743
PL
Relay
DDB
No.
English Text Type Source Description
P741
152
PU Error Alm z8
PSL Input Signal
Scheme Integrity
PU error alarm in zone 8
P741
281
PU Error Alm Zx
PSL Input Signal
Scheme Integrity
PU error Alarm in Zone x
Logical OR of DDB 152 to 159
P741
151
PU Error Lck z1
PSL Input Signal
Scheme Integrity
PU error blocking of zone 1
P741
144
PU Error Lck z8
PSL Input Signal
Scheme Integrity
PU error blocking of zone 8
P741
282
PU Error Lck Zx
PSL Input Signal
Scheme Integrity
PU error blocking Zone x
Logical OR of DDB 144 to 151
P741
287
PU Error Lock CZ
PSL Input Signal
Scheme Integrity
PU error blocking the Check Zone
P741
391
PU Error Reset
PSL Input Signal
Scheme Integrity
Reset PU Error alarm and / or blocking
P741
390
PU Topo invalid
PSL Input Signal
Scheme Integrity
Topology file error for one or several PU
P741
368
PU->CU Signal
01
PSL Input Signal
PSL
Virtual Signal 01 from any PU to the CU via the
fibre optic
P741
383
PU->CU Signal
16
PSL Input Signal
PSL
Virtual Signal 16 from any PU to the CU via the
fibre optic
P741
1280
PubPres VIP 1
PSL Input Signal
PSL
Publishing presence of virtual input 1: indicates
virtual input 1 presence.
P741
1343
PubPres VIP 64
PSL Input Signal
PSL
Publishing presence of virtual input 64: indicates
virtual input 64 presence.
P741
1152
Quality VIP1
PSL Input Signal
PSL
Validation of the virtual input 1 (signal correct).
P741
1215
Quality VIP64
PSL Input Signal
PSL
Validation of the virtual input 64 (signal correct).
P741
700
Relay condit 01
OUTPUT_CON
Output Conditioner
Input to Relay Output Conditioner
P741
707
Relay condit 08
OUTPUT_CON
Output Conditioner
Input to Relay Output Conditioner
P741
0
Relay Label 01
RELAY
Output Conditioner
Output Relay 01
P741
7
Relay Label 08
RELAY
Output Conditioner
Output Relay 08
P741
106
Reset CircFlt
PSL Output
Signal
PSL
To Reset the Circuitry Fault
P741
109
Reset Indication
PSL Output
Signal
PSL
Reset all indications (Led and relays latched in
PSL)
that includes the Led Alarm
P741
110
Reset PU Error
PSL Output
Signal
PSL
To reset PU error
P741
393
RP1 Read Only
PSL Output
Signal
PSL
All setting changes and most command/control
actions blocked for Rear Port 1.
P741
394
RP2 Read only
PSL Output
Signal
PSL
All setting changes and most command/control
actions blocked for Rear Port 2 (when option
available)
P741
283
SEF Blocked
PSL Input Signal
87BB SEF Busbar
Protection
87BB SEF blocked by opto input
Logical OR of DDB 208 to 215
P741
104
Sett Grp Bit LSB
PSL Output
Signal
PSL
Setting Group Selector X1 (low bit)
SG1 is active DDB 104=0 & DDB 105=0
SG2 is active DDB 104=1 & DDB 105=0
P741
105
Sett Grp Bit MSB
PSL Output
Signal
PSL Input signal
Setting Group Selector 1X (high bit)
SG3 is active DDB 104=0 & DDB 105=1
SG4 is active DDB 104=1 & DDB 105=1
P741
388
Topo/Set
Changed
PSL Input Signal
Group Selection
Change on topology or configuration
P741
270
Topology valid
PSL Input Signal
Scheme Integrity
Valid Topology file
P741
259
Trip 50BF
PSL Input Signal
50BF Backtrip
protection
Breaker fail trip order (50BF)
Logical OR of DDB 200 to 207
P741
260
Trip 50BF Locked
PSL Input Signal
Scheme Integrity
Breaker fail trip order blocked by commissioning
mode or Circuitry fault
P741
207
Trip 50BF Zone 1
PSL Input Signal
50BF Backtrip
protection
Breaker failure trip (50BF) of zone 1
P741
200
Trip 50BF Zone 8
PSL Input Signal
50BF Backtrip
protection
Breaker failure trip (50BF) of zone 8
P741
256
Trip 87BB
PSL Input Signal
87BB Busbar
Protection
Busbar trip order (87BB)
Logical OR of DDB 184 to 191
P741
257
Trip 87BB Locked
PSL Input Signal
Scheme Integrity
Busbar trip order blocked by commissioning
mode or Circuitry fault
P741
191
Trip 87BB Zone 1
PSL Input Signal
87BB Busbar
Protection
Busbar trip of zone 1
P741
184
Trip 87BB Zone 8
PSL Input Signal
87BB Busbar
Protection
Busbar trip of zone 8
P741
258
Trip Manual zone
PSL Input Signal
Commissioning
Manual Trip Order Logical OR of DDB 192 to
199
P741
136
User Alarm 1
PSL Output
Signal
PSL
Triggers User Alarm 1 message to be alarmed
on LCD display (self-resetting)
P741
143
User Alarm 8
PSL Output
Signal
PSL
Triggers User Alarm 8 message to be alarmed
on LCD display (self-resetting)
P741
1024
virtual input 1
GOOSEIN
GOOSE Input
Command
Virtual Input 1
Allows binary signals that are mapped to virtual
inputs to interface into PSL
