GE P742

Programmable Logic
P74x/EN PL/N
a7
MiCOM P74
1, P742, P743
(PL) 7-
37
PL
Relay
DDB
No.
English Text Type Source Description
P743
347
CB Trip phase A
PSL Input Signal
50BF Protection
Phase A Circuit Breaker Trip (Init 50BF TBF3 /
TBF4), Logical OR of :
O/C Protection, External Trip A, External Trip
3ph
P743
348
CB Trip phase B
PSL Input Signal
50BF Protection
Phase B Circuit Breaker Trip (Init 50BF TBF3 /
TBF4), Logical OR of :
O/C Protection, External Trip B, External Trip
3ph
P743
349
CB Trip phase C
PSL Input Signal
50BF Protection
Phase C Circuit Breaker Trip (Init 50BF TBF3 /
TBF4), Logical OR of :
O/C Protection, External Trip C, External Trip
3ph
P743
351
General Alarm
PSL Input Signal
Relay Integrity
General Alarm
P743
352
CB Status Alarm
PSL Input Signal
Scheme Integrity
Indication of discrepancy between the 52a and
52b auxiliary contacts of the Circuit Breaker
P743
353
Man CB Cls Fail
PSL Input Signal
Scheme Integrity
Circuit Breaker Failed to Close
(after a manual/operator close command)
P743
354
Man CB Trip Fail
PSL Input Signal
Scheme Integrity
Circuit Breaker Failed to Trip
(after a manual/operator trip command)
P743
355
Ctrl Cls in Prog
PSL Input Signal
Commissioning
Control Close in Progress
The relay has been given an instruction to close
the circuit breaker, but the Manual Close timer
Delay has not yet finished timing out
P743
356
Control Close
PSL Input Signal
Commissioning
Control Close command to the circuit breaker.
Operates for a manual close command (menu,
SCADA)
P743
357
Control Trip
PSL Input Signal
Commissioning
Control Trip
Operator trip instruction to the circuit breaker,
via menu, or SCADA. (Does not operate for
protection element trips)
P743
358
Any Trip
PSL Input Signal
All Protections
Any Trip (Logical OR of ddbs:
0, 1, 2, 168, 169, 170, 171, 256, 261)
P743
436
Timer in 436
TIMERIN
PSL Timer Input
Input to Auxiliary Timer 1
P743
451
Timer in 451
TIMERIN
PSL Timer Input
Input to Auxiliary Timer 16
P743
452
Timer out 452
TIMEROUT
Timer Output
Output from Auxiliary Timer 1
P743
362
RP1 Read only
PSL Output
signal
PSL
All setting changes and most command/control
actions blocked for Rear Port 1.
P743
363
RP2 Read only
PSL Output
signal
PSL
All setting changes and most command/control
actions blocked for Rear Port 2 (when option
available).
P743
364
NIC Read Only
PSL Output
signal
PSL
All setting changes and most command/control
actions blocked for the Ethernet port (when
option available).
P743
376
87BB Fault Ph A
PSL Output
signal
PSL
87BB Phase Fault detected in phase A
P743
377
87BB Fault Ph B
PSL Output
signal
PSL
87BB Phase Fault detected in phase B
P743
378
87BB Fault Ph C
PSL Output
signal
PSL
87BB Phase Fault detected in phase C
P743
379
87BB Earth Fault
PSL Output
signal
PSL
87BB earth Fault detected
P743
467
Timer out 467
TIMEROUT
Timer Output
Output from Auxiliary Timer 16
P743
468
Fault_REC_TRIG
FRT
PSL
Trigger for the Fault Recorder
P743
469
Battery Fail
PSL Input Signal
Relay Integrity
Front panel Battery Failure
P743
470
Field Voltage Fail
PSL Input Signal
Relay Integrity
48V Field Voltage Failure
P743
471
Comm2 H/W
FAIL
PSL Input Signal
Second rear port
Second rear port Alarm
P743
472
GOOSE IED
Absent
PSL Input Signal
IEC 61850
The IED is not subscribed to a publishing IED in
the current scheme
P743
473
NIC Not Fitted
PSL Input Signal
IEC 61850
Ethernet board not fitted
P743
474
NIC No
Response
PSL Input Signal
IEC 61850
Ethernet board not responding
P743
475
NIC Fatal Error
PSL Input Signal
IEC 61850
Ethernet board unrecoverable error
P743
476
NIC Soft. Reload
PSL Input Signal
IEC 61850
Ethernet card software reload Alarm
P743
477
Bad TCP/IP Cfg.
PSL Input Signal
IEC 61850
Bad TCP/IP configuration alarm
P743
478
Bad OSI Config.
PSL Input Signal
IEC 61850
Bad OSI configuration alarm
P743
479
NIC Link Fail
PSL Input Signal
IEC 61850
Ethernet link lost
P743
480
NIC SW Mis-
Match
PSL Input Signal
IEC 61850
Ethernet board software not compatible with
main CPU
P743
481
IP Addr Conflict
PSL Input Signal
IEC 61850
The IP address of the IED is already used by
another IED
P743
482
IM Loopback
PSL Input Signal
InterMiCOM
InterMiCOM indication that Loopback testing is
in progress
P743
483
IM Message Fail
PSL Input Signal
InterMiCOM
InterMiCOM Message Failure Alarm
