Programmable Logic
(PL)
7-
38
MiCOM P74
1, P742, P743
PL
Relay
DDB
No.
English Text Type Source Description
P743
484
IM Data CD Fail
PSL Input Signal
InterMiCOM
InterMiCOM Data Channel Detect Fail
P743
485
IM Channel Fail
PSL Input Signal
InterMiCOM
InterMiCOM Channel Failure Alarm
P743
486
Backup Setting
PSL Input Signal
InterMiCOM
Backup setting Alarm
This is an alarm that is ON if any setting fail
during the setting changing process. If this
happens, the relay will use the last known good
setting.
P743
512
GOOSE OUT 1
GOOSEOUT
PSL
GOOSE Output 1
Allows user to control a binary signal which can
be mapped via SCADA protocol output to other
devices
P743
543
GOOSE OUT 32
GOOSEOUT
PSL
GOOSE Output 32
Allows user to control a binary signal which can
be mapped via SCADA protocol output to other
devices
P743
584
InterMiCOM in 1
INTERIN
InterMiCOM
InterMiCOM IM1 Signal Input - is driven by a
message from the remote line end
P743
591
InterMiCOM in 8
INTERIN
InterMiCOM
InterMiCOM IM8 Signal Input - is driven by a
message from the remote line end
P743
592
InterMiCOM out 1
INTEROUT
InterMiCOM
InterMiCOM IM1 Signal Output - mapping what
will be sent to the remote line end
P743
599
InterMiCOM out 8
INTEROUT
InterMiCOM
InterMiCOM IM8 Signal Output - mapping what
will be sent to the remote line end
P743
600
CBF I< Start A
PSL Output
Signal
50BF Protection
Phase A undercurrent CBF Dead Pole Start
P743
601
CBF I< Start B
PSL Output
Signal
50BF Protection
Phase B undercurrent CBF Dead Pole Start
P743
602
CBF I< Start C
PSL Output
Signal
50BF Protection
Phase C undercurrent CBF Dead Pole Start
P743
603
CBF I> Start A
PSL Output
Signal
50BF Protection
Phase A overcurrent CBF Dead Pole Start
P743
604
CBF I> Start B
PSL Output
Signal
50BF Protection
Phase B overcurrent CBF Dead Pole Start
P743
605
CBF I> Start C
PSL Output
Signal
50BF Protection
Phase C overcurrent CBF Dead Pole Start
P743
606
CBF I> Start N
PSL Output
Signal
50BF Protection
Neutral overcurrent CBF Dead Pole Start
P743
608
Control Input 1
CONTROL
Control Input
Command
Control Input 1 - for SCADA and menu
commands into PSL
P743
639
Control Input 32
CONTROL
Control Input
Command
Control Input 32 - for SCADA and menu
commands into PSL
P743
640
LED 1 Red
TRI_LED
PSL (LED)
Programmable LED 1 Red is energized
P743
641
LED 1 Grn
TRI_LED
PSL (LED)
Programmable LED 1 Green is energized
P743
654
LED 8 Red
TRI_LED
PSL (LED)
Programmable LED 8 Red is energized
P743
655
LED 8 Grn
TRI_LED
PSL (LED)
Programmable LED 8 Green is energized
P743
656
FnKey LED 1
Red
TRI_LED
PSL (LED)
Programmable Function Key LED 1 Red is
energized
P743
657
FnKey LED 1 Grn
TRI_LED
PSL (LED)
Programmable Function Key LED 1 Green is
energized
P743
674
FnKey LED 10
Red
TRI_LED
PSL (LED)
Programmable Function Key LED 10 Red is
energized
P743
675
FnKey LED 10
Grn
TRI_LED
PSL (LED)
Programmable Function Key LED 10 Green is
energized
P743
676
Function Key 1
FUNCTION_KEY
PSL (Function Key)
Function Key 1 is activated.
In ‘Normal’ mode it is high on key press and in
‘Toggle’ mode remains high/low on single key
press
P743
685
Function Key 10
FUNCTION_KEY
PSL (Function Key)
Function Key 10 is activated.
In ‘Normal’ mode it is high on key press and in
‘Toggle’ mode remains high/low on single key
press
P743
700
Relay condit 01
OUTPUT_CON
Output Conditioner
Input to Relay Output Conditioner
P743
715
Relay condit 16
OUTPUT_CON
Output Conditioner
Input to Relay Output Conditioner
P743
764
LED 1 Red
Condit
TRI_LED_CON
Output Conditioner
Assignment of input signal to drive output LED
1Red
P743
765
LED 1 Grn Condit
TRI_LED_CON
Output Conditioner
Assignment of signal to drive output LED
1Green.
To drive LED1 Yellow DDB 764 and DDB 765
must be driven at the same time
P743
778
LED 8 Red
Condit
TRI_LED_CON
Output Conditioner
Assignment of signal to drive output LED 8Red
