GE P742

Programmable Logic
P74x/EN PL/N
a7
MiCOM P74
1, P742, P743
(PL) 7-
53
PL
LED
Number
LED Input Connection/Text Latched P74x LED Function Indication
10
FnKey LED2 Red
FnKey LED2 Yellow
FnKey LED2 Green
No
Not used
Not used
Reset PU Trip Latch
11
FnKey LED3 Red
FnKey LED3 Yellow
FnKey LED3 Green
No Not used
12
FnKey LED4 Red
FnKey LED4 Yellow
FnKey LED4 Green
No
Not used
Mode 50BF disabled
Mode normal
13
FnKey LED5 Red
FnKey LED5 Yellow
FnKey LED5 Green
No
Mode overhaul
Not used
Mode normal
14
FnKey LED6 Red
FnKey LED6 Yellow
FnKey LED6 Green
No Not used
15
FnKey LED7 Red
FnKey LED7 Yellow
FnKey LED7 Green
No Not used
16
FnKey LED8 Red
FnKey LED8 Yellow
FnKey LED8 Green
No Not used
17
FnKey LED9 Red
FnKey LED9 Yellow
FnKey LED9 Green
No Not used
18
FnKey LED10 Red
FnKey LED10 Yellow
FnKey LED10 Green
No Not used
