IP8820/IP8830/IP8840
Installer Guide
D-14
Section
Field Name
Description
func
Optional parameter that specifies the function for flexible
buttons not assigned as a line.
Valid values are:
• 1 — Speed Dial
• 2 — Phonebook
• 3 — Call Log
• 4 — Mute
• 5 — Headset
• 6 — Last number redial
• 7 — Last call return
• 8 — Forward
• 9 — Conference
• 10 — Transfer
• 11 — Hold
• 12 — DND
• 13 — Ringer Off
• 14 — Message
The default is blank.
num
Specifies the number for a Speed dial or Message button.
The default is blank.
prog
Specifies the flexible button number being assigned.
Valid values are
• IP8820 — 1 to 12 or 1 to 24 (w/ Expansion Module)
• IP8830 — 1 to 24 or 1 to 36 (w/ Expansion Module)
• IP8840 — 1 to 10 or 1 to 22 (w/ Expansion Module)
The default is blank.
label
string
Specifies the label for flexible buttons.
The maximum length is 15-characters, 12 display on IP8840,
10 display on IP8812LSS.
The default is blank.
callnum_in_line
Assigns the max number of active calls.
Valid value is 1 ~ 3.
The default is three (3).
anonymous_call_blk
Controls blocking incoming calls with an anonymous caller id.
Valid values are enable or disable.
The default is disable.
call_waiting
Controls visual notification of incoming call while busy.
Valid values are enable or disable.
Default is enable.
call_waiting_tone
Controls audible notification when Call Waiting is enabled
Valid values are enable or disable.
Default is enable.
call_hold_ringback
Sets Held call ringback. If a user returns to idle with a call on
hold, the held line will ring.
Valid values are enable and disable.
Default is enable.
msg_waiting_tone
Controls stutter dial tone when there is a message waiting.
Valid values are enable or disable.
Default is enable.
CALL
auto_answer
Controls answering an incoming call automatically activating
the speakerphone or headset.
Valid values are enable or disable.
Default is disable.
