9.3 Communication Methods
133
99
Status Byte Register (STB)
During serial polling, the contents of the 8-bit Status Byte Register are sent from
the instrument to the controller.
When any Status Byte Register bit enabled by the Service Request Enable Reg-
ister has switched from 0 to 1, the MSS bit becomes 1. Consequently, the SRQ
bit is set to 1, and a service request is dispatched.
The SRQ bit is always synchronous with service requests, and is read and simul-
taneously cleared during serial polling. Although the MSS bit is only read by an
∗STB? query, it is not cleared until a clear event is initiated by the ∗CLS com-
mand.
Service Request Enable Register (SRER)
This register masks the Status Byte Register. Setting a bit of this register to 1
enables the corresponding bit of the Status Byte Register to be used.
Bit 7
unused
Bit 6
SRQ
Set to 1 when a service request is dispatched.
MSS
This is the logical sum of the other bits of the
Status Byte Register
.
Bit 5
ESB
Standard Event Status (logical sum) bit
This is logical sum of the Standard Event Status Register.
Bit 4
MAV
Message available
Indicates that a message is present in the output queue.
Bit 3
unused
Bit 2
unused
Bit 1
unused
Bit 0
ESB0
Event Status (logical sum) bit 0
This is the logical sum of Event Status Register 0.
