9.4 Message Reference
164
Queries the contents of the set-value memory for withstand-voltage tests
Syntax
(Query)
:MEMory:WITHstand:FILE? <1 to 8 (NR1)>
Queries the contents of the set-value memory for the withstand-volt-
age test number specified.
(Response)
<Test frequency>,<Test voltage>,<Current upper-limit value>,
<Current lower-limit value>,<Test time>,
<Ramp-up time>,<Ramp-down time>,<initial voltage for ramp-up>
<contact check upper-limit voltage>,
<contact check lower-limit voltage>
Test frequency..............................0/1 (NR1)
0: AC50 Hz
1: AC60 Hz
Test voltage..................................0.20 to 5.00 (NR2, unit: kV)
Current upper-limit value..............0.1 to 20.0 (NR2, unit: mA)
Current lower-limit value ..............0.1 to 19.9 (NR2, unit: mA)
0: OFF
Test time.......................................0.3 to 999 (NR1/NR2, unit: s)
0: OFF
Ramp-up time ..............................0.1 to 99.9 (NR2, unit: s)
0: OFF
Ramp-down time.......................... 0.1 to 99.9 (NR2, unit: s)
0: OFF
initial voltage for ramp-up............. 0.0 to 1.0 (NR2, unit: kV)
contact check upper-limit voltage. 0.20 to 5.00 (NR2, unit: kV)
0: OFF
contact check lower-limit voltage .0.20 to 5.00 (NR2, unit: kV)
0: OFF
Example
(Query)
:MEMory:WITHstand:FILE? 1
Queries the contents of set-value memory file 1 for withstand-voltage tests.
(Response)
0,1.20,5.0,0,20.0,5.0,0,0.2,2.00,1.00
50 Hz AC-withstand-voltage test; Test voltage: 1.2 kV; Upper-limit value: 5 mA;
Lower-limit value: OFF; Test time: 20.0 s; Ramp-up time: 5.0 s; Ramp-down
time: OFF; initial voltage for ramp-up
0.2 kV; contact check upper-limit voltage:
2 kV; contact check lower-limit voltage:1 kV
Error
An execution error occurs when file numbers other than 1 to 8 are specified.
Loads the set-value memory for withstand-voltage tests
Syntax
(Command)
:MEMory:WITHstand:LOAD <1 to 8 (NR1)>
Loads the data saved for the withstand-voltage test file numbers
specified.
Example :MEMory:WITHstand:LOAD 1
Loads memory file 1 for withstand-voltage tests.
Error
The execution of this command in a state other than the withstand-voltage mode
READY state causes an execution error.
The execution of this command in the insulation-resistance mode also causes an
execution error.
An execution error occurs when file numbers other than 1 to 8 are specified.
