9.4 Message Reference
171
99
Queries the insulation-resistance test result
Syntax
(Query)
:MEASure:RESult:INSulation?
Queries the results of the preceding test. Returns the determination
and valid values at termination of the preceding test. The test results
are updated upon termination of a new test.
(Response)
<Insulation-resistance test measured voltage value>,
<Measured resistance value>,<Test time elapsed>,<Determination>,
<Types of timers>
Insulation-resistance test measured voltage value
.............................................(NR1, unit: V)
Measured resistance value.. (NR1/NR2, unit: MΩ)
9999: O.F.
0.0 : U.F.
0: No value
Test time elapsed................. (NR2, unit: s)
Determination ...................... PASS/ UFAIL/ LFAIL/ ULFAIL/ OFF
PASS : PASS
UFAIL : UPPER-FAIL
LFAIL : LOWER-FAIL
ULFAIL : UPPER-LOWER-FAIL
OFF :
Others
Types of timers .................... 0/ 1 (NR1)
0 : Test time
1: Delay time
Example
(Query)
:MEASure:RESult:INSulation?
(Response)
500,100,10.0,PASS,0
Measured voltage value: 500 V; Measured resistance value: 100 MΩ; Test
time elapsed: 10.0 s; Determination: PASS; Types of timers: Test time
Note
Contact error type will not return.
Queries the measured voltage value for insulation-resistance tests
Syntax
(Query)
:MEASure:INSulation:VOLTage?
Queries the measured voltage value (unit: V) for insulation-resistance
tests.
(Response)
<Measured voltage value for insulation-resistance tests (NR1)>
Example
(Query)
:MEASure:INSulation:VOLTage?
(Response)
500
The measured voltage value is 500 V.
Error
The execution of this command in a state other than the TEST state causes an
execution error.
