9.4 Message Reference
177
99
Sets the optional functions 2
Syntax
(Command)
:SYStem:OPTion:P2
<Insulation-resistance test measurement range>,
<Insulation-resistance test termination mode>,
<PC interface>,<START protection function>,<TEST-signal output>,
<Forced termination’s evaluation output>,
<Continuous Test mode>,<GP-IB address>
Sets the contents on Page 2 of the Optional Function Setting Screen.
(Data)
Insulation-resistance test measurement range...0/1 (NR1)
0: Fixed range
1: Auto range
Insulation-resistance test termination mode .......0/1/2 (NR1)
0: Test for set time
1: Terminate test at PASS
2: Terminate test at FAIL
PC interface....................0/1/2 (NR1)
0: RS-232C (9600bps)
1: RS-232C (19200bps)
2: GP-IB
START protection function... 0/1 (NR1)
0: Not set
1: Set
TEST-signal output .........0/1/2 (NR1)
0: TEST signal ON, while all test time including
ramp-up and ramp-down time
1: TEST signal ON, while set test time
2: TEST signal ON, only while ramp-up and
ramp-down time
Forced termination’s
evaluation output ............0/1 (NR1)
0: No evaluation
1: Evaluation
Continuous Test mode....0/1 (NR1)
0: Test stops when FAIL appears.
1: Test continues when
FAIL appears
GP-IB address ................1 to 30 (NR1)
Example
(Command)
:SYStem:OPTion:P2 0,2,2,1,1,0,0,15
Set the contents on Page 2 of the Optional Function Setting as follows.
Insulation-resistance test measurement range: Fixed range,
Insulation-resistance test termination mode: Terminate test at FAIL,
PC interface: GP-IB,
START protection function: Set,
TEST-signal output: TEST signal ON, while set test time,
Forced termination’s evaluation output: No evaluation,
Continuous Test mode: Test stops when FAIL appears,
GP-IB address: 15
Error
• The execution of this command in a state other than the READY state causes
an execution error.
• Execution error appears when value other than specified is set.
