9.4 Message Reference
178
Queries the optional functions 2
Syntax
(Query)
:SYStem:OPTion:P2?
Query contents on Page 2 of the Optional Function Setting Screen.
(Response)
<Insulation-resistance test measurement range>,
<Insulation-resistance test termination mode>,
<PC interface>,<START protection function>,<TEST-signal output>,
<Forced termination’s evaluation output>,
<Continuous Test mode>,<GP-IB address>
Insulation-resistance test measurement range .. 0/1 (NR1)
0: Fixed range
1: Auto range
Insulation-resistance test termination mode....... 0/1/2 (NR1)
0: Test for set time
1: Terminate test at PASS
2: Terminate test at FAIL
PC interface ....................0/1/2 (NR1)
0: RS-232C (9600bps)
1: RS-232C (19200bps)
2: GP-IB
START protection function ...0/1 (NR1)
0: Not set
1: Set
TEST-signal output .........0/1/2 (NR1)
0: TEST signal ON, while all test time including
ramp-up and ramp-down time
1: TEST signal ON, while set test time
2: TEST signal ON, only while ramp-up and
ramp-down time
Forced termination’s
evaluation output.............0/1 (NR1)
0: No evaluation
1: Evaluation
Continuous Test mode ....0/1 (NR1)
0: Test stops when FAIL appears.
1: Test continues when
FAIL appears
GP-IB address ................1 to 30 (NR1)
Example
(Query)
:SYStem:OPTion:P2?
(Response)
0,2,2,1,1,0,0,15
Insulation-resistance test measurement range: Fixed range,
Insulation-resistance test termination mode: Terminate test at FAIL,
PC interface: GP-IB,
START protection function: Set,
TEST-signal output: TEST signal ON, while set test time,
Forced termination’s evaluation output: No evaluation,
Continuous Test mode: Test stops when FAIL appears,
GP-IB address: 15
