9 Servicing
RPK-FSN(H)3M - Wall mounted
SMGB0099 rev.0 - 12/2016
309
9
Attaching at panel.
Insert completely the left and right arm shafts of at panel into
the holes along the guide at the front panel. After the at panel is
attached completely, insert the catches for air lter to x it.
Flat panel
Front panel
Hole
Guide at
front panel

For RPK-(2.0-4.0)FSN(H)3M
1 Remove the air lter according to the “9.9.1 Removal of the air lter” chapter.
2 Open the at panel fully and push the right arm shaft inward. After the shaft is removed from the front panel, pull the
at panel frontward with the right arm shaft slightly pushed inward and then remove the at panel.
3 Remove 3 bushes and then 3 screws. Pull the lower side of the front panel (2 portions) forward to release the
catches. Use a slotted screwdriver when the catches are difcult to release.
! CAUTION
Take special care not to be injured by the heat exchanger ns.
4 Remove the front panel carefully so that it does not touch the horizontal louver attached to the air outlet. Slightly lift
the front panel up to release the catches (4 portions) on the upper side of the unit. Then pull the front panel forward to
remove it.
? NOTE
When releasing the catches, snap sound is heard. This is the sound made when the catches are released and so there are no safety
concerns.
Flat panel
Push the shaft
toward arrow
direction
Remove this part
from the hole
When using a slotted
screwdriver, insert
it into the gap and
push the catches
downwards
Bush
Screw
Drain pan projection
portion for catches
Catches on lower
side of front panel
Holes for catches
