readback of the motor encoder (in the example below, it is 2048). Manually rotate the
encoder until the readback is 1000±100 (i.e., in the range 900-1100) and then secure the
encoder to the drive shaft.
Repeat the calibration procedure above but now, when TX hits the outer mechanical stop,
5.
Press
<Enter>
.
The program switches to graphics mode and draws the Encoder Vs Distance calibration grid.
It moves the TZ motor to its topmost position and then steps the TX motor in by 1"
increments until the inner mechanical stop is hit (while simultaneously rotating the C-arm to
keep the table and C-arm from hitting). The program plots the encoder data during the scan
(in raw encoder units, 0-4095).
6.
Press
<ESC>
at anytime during the scan to terminate the calibration procedure.
MotionState NONE OnLine 1
DeviceState E_OK EmergencyStop 0
MotionError E_OK InterlockInhibit 0
PosMotionSwitch 0 CollisionImminent 0
NegMotionSwitch 0 LocalMotionEnable 0
PosLimitSwitch NONE C/C Version 0.00
NegLimitSwitch NONE # C/C Interrupts 1133(0)
Position 298545 # DOS Interrupts 191
MoveState DONE StepStatus 0
FirstRate 3600 AccelType 1
FinalRate 36003 Direction 1
HoldPower LOW HoldPower 1
StepPower MEDIUM StepPower 2
AccelDistance 2004 InputSwitches 3
AccelType 1
Position 2048
MinMotion 0 NegLimitPosition 1026
MotionDetect 0 PosLimitPosition 3096
PosLimitPosition 604684 FirstRate 300
NegLimitPosition 0 FinalRate 3000
PositionAverage 1 AccelSteps 167
DriverVersion 3.41 NumberOfSteps 50000
DeviceVersion 2.03 RateScaleFactor 1
T1 T
MOTOR$TX>
