QDR
®
4500 Technical Manual
2-14
Table 2-9. Control Panel Controller/Control Panel Interconnection
Descriptions
Signal Description CPC
1
Pin
CP
2
Pin
L0_PWR* Turns on the ENABLE switch LED. JP6-11 JP1-11
L1_PWR* Turns on the HOME switch LED. JP6-12 JP1-12
L2_PWR* Turns on the LOAD switch LED. JP6-13 JP1-13
L3_PWR* Turns on the TABLE switch IN/OUT LED. JP6-14 JP1-14
L4_PWR* Not used. JP6-15 JP1-15
L5_PWR* Turns on the C-ARM switch RIGHT/LEFT LED. JP6-16 JP1-16
L6_PWR* Not used. JP6-17 JP1-17
L7_PWR* Turns on the Laser LED. JP6-18 JP1-18
TZ_PWR* Turns on the TABLE UP LED. JP6-20 JP1-20
XRAY_LIGHT_PWR* Turns on the X_RAY LED JP6-19 JP1-19
SW0 Control signal to determine the state of the C-ARM and
LASER switches.
JP6-4 JP1-4
SW1 Control signal to determine the state of the TABLE
IN/OUT switches.
JP6-5 JP1-5
SW2 Control signal to determine the state of the LOAD, HOME
and ENABLE switches.
JP6-6 JP1-6
SR0 Returns the state of the C-ARM switch LEFT position
when SW0 is active. Signals the state of the TABLE
switch IN position when SW1 is active. Signals the state
of the LOAD switch when SW2 is active.
JP6-1 JP1-1
SR1 Returns the state of the C-ARM switch RIGHT position
when SW0 is active. Signals the state of the TABLE
switch OUT position when SW1 is active. Signals the
state of the HOME switch when SW2 is active.
JP6-2 JP1-2
SR2 Returns the state of the LASER and ENABLE switches
when SW2 is active.
JP6-3 JP1-3
MAN_TZ_UP
MAN_TZ_UP_RET
Returns the state of the TABLE switch UP position. JP6-7
JP6-8
JP1-7
JP1-8
MAN_TZ_DOWN
MAN_TZ_DOWN_RET
Not Used. JP6-9
JP6-10
JP1-9
JP1-10
EMERGENCY_CPANEL
HW_EMERGENCY_RET
Returns the state of the STOP switch. (Part of the safety
daisy chain.)
JP6-23
JP6-24
JP1-23
JP1-24
+5V Provides power for the Control Panel LEDs. JP6-21
JP6-22
JP1-21
JP1-22
Notes: 1. CPC = Control Panel Controller
2. CP = Control Panel
