C300 Controller Block
FTE tab
88 Experion C300 Controller User's Guide R301.1
Honeywell 11/06
Plain Text Parameter Name
User
Configurable
Notes
Programmable Logic
Version
PLREVISION
No
Identifies the version of
the programmable logic
set of the module.
Hardware Major
Revision
HWREVMAJ
No
Identifies the major
hardware revision number
of the module.
Hardware Minor
Revision
HWREVMIN
No
Identifies the minor
hardware revision number
of the module.
Network Interface Address Information
FTE Interface A MAC
Address
MACADDRA
No
Identifies Ethernet MAC
Address of FTE Interface
A (Yellow Tree Port)
FTE Interface B MAC
Address
MACADDRB
No
Identifies Ethernet MAC
Address of FTE Interface
B (Green Tree Port)
Redun. Interface
MAC Address
MACADDRR
No
Identifies Ethernet MAC
Address of Redundancy
Interface.
Note 1: IMAGEVER is also provided on the Main Tab; it is provided here with other version
information related to the C300.
FTE tab
The FTE tab contains statistics related to Fault Tolerant Ethernet (FTE) communications
and performance. The FTE tab features parameters associated with the MAC Address
Resolution Table (MART), which deals with on-line media access control (MAC)
address mapping. Two separate MARTs are maintained – one for FTE nodes and one for
non-FTE nodes.
The following table summarizes the parameter data you can monitor on the FTE tab of
the configuration form for the selected C300 block.
Plain Text Parameter Name
User
Configurable
Notes
FTE
