Assign Control Modules and IOMs to a CEEC300 block
To assign Control Modules and IOMs to a CEE
R301.1 Experion C300 Controller User's Guide 61
11/06 Honeywell
Prerequisites
• Control Builder is running
• Tree windows are open
Considerations
All illustrations used in the procedure are for example purposes only.
For additional information on CM assignment, see the Control Building Guide; or for
SCM assignment, the Sequential Control User’s Guide.
ATTENTION
• Before Control Builder allows you to associate an IOM to an
IOCHANNEL block, it checks to make sure that the CM and IOM are
assigned to the same CEE
• All edit windows (such as CM charts) must be closed before
proceeding with this procedure or a lock contention may occur. To
resolve these types of lock contentions, close the open CM chart and
attempt to open the CM chart again.
To assign Control Modules and IOMs to a CEE
Step Action Result
1
Click Edit->Execution Environment
Assignment. Or, click
assignment
button in the toolbar.
Calls up Execution Environment
Assignment dialog box. (There is no set
default state for the dialog, so it may
come up with different active fields than
shown below.)
To Next Page
