Create a Control Module
To build a Control Strategy, a Control Module (CM) must be created where function
blocks are inserted and connected with other function blocks. The following graphic
shows Control Builder with a Control Module chart shown in the control drawing area.
Prerequisites
• Control Builder is running
• Tree windows are open
Considerations
All illustrations used in the procedure are for example purposes only.
