C300 Configuration Form Reference
This section provides a summary all of the user visible parameters for a C300 Controller
and its associated blocks, (Secondary C300, CEEC300, and IOLINK blocks). The
parameters are grouped according to the tab where they reside in the configuration form.
For more details on these parameters see the Control Builder Parameter Reference.
Click on the topic in the table to view the parameters listed in that block’s configuration
form.
Topic
C300 Controller block
Secondary C300 block
CEEC300 function block
IOLINK block
C300 Controller Block
Main tab
The Main Tab is used to configure (and display configuration of) the C300 Controller.
See To configure a C300 Controller block
for the steps to configure a C300 Controller
block. The Main tab contains most of the parameters that must be configured when
setting up a C300 Controller. It also displays the important states of the C300 Controller
and supports the key commands associated with C300 Controller operation. Location and
Redundancy configuration can be done only in the Project Tree. The following table
summarizes the parameter data you can monitor and/or configure on the Main tab of the
configuration form for the selected C300 block.
Plain Text Parameter Name
User
Configurable
Notes
Tag Name
Tag Name
Project Only
System assigned or user
configured unique name.
Consisting of up to 16
characters and at least
one character must be a
letter (A-Z).
