C300 Controller Block
IP/ICMP tab
R301.1 Experion C300 Controller User's Guide 95
11/06 Honeywell
Plain Text Parameter Name
User
Configurable
Notes
Reset Segments
Sent
TCPOUTRESETS
No
Number of TCP segments
sent containing the RST
flag.
IP/ICMP tab
The IP/ICMP tab displays statistics related to IP and ICMP protocol messages associated
with (i.e. originating in or received by) this C300 Controller. These types of messages are
generally associated with maintenance and status operations on the network. The
following table summarizes the parameter data you can monitor on the IP/ICMP tab of
the configuration form for the selected C300 block.
Plain Text Parameter Name
User
Configurable
Notes
IP Statistics –
(Provides packet delivery services between nodes.)
Datagrams Received
from Below
IPINRECEIVES
No
Total number of input
datagrams received from
connected nodes,
including those received in
error.
Datagrams Format
Errors Drops
IPINHDRERRORS
No
Number of input
datagrams discarded due
to errors in their Internet
Protocol (IP) headers,
including bad checksums,
version number mismatch,
other format errors, time-
to-live exceeded, errors
discovered in processing
their IP options, etc.
Datagrams
Misdelivery Drops
IPINADDRERRORS
No
Number of input
datagrams discarded
because the IP address in
their IP header's
destination field was not a
valid address to be
received at this entity.
To Next Page
