Series C control hardware
C300 Controller
10 Experion C300 Controller User's Guide R301.1
Honeywell 11/06
REFERENCE - INTERNAL
For more details about Series C I/O and FIM modules refer to the Series C
I/O User’s Guide and the Series C Fieldbus Interface Module User’s Guide.
C300 Controller
The C300 Controller is constructed using the Series C form factor that employs an Input
Output Termination Assembly (IOTA) and an electronics module which mounts and
connects to the IOTA. One C300 Controller contains all of the control functionality and
most of the communications functions that previously required a C200 controller chassis
filled with plug-in modules. This smaller controller footprint and ease of installation,
combined with enhanced functionality that is built upon C200 performance, provides
greater value for Experion users.
The C300 Controller fully supports configuration, load and execution of the standard
function blocks supported in previous Experion releases, (R210). Note that there are a
few exceptions defined below.
Exceptions
The following function blocks are not supported by the C300 Controller in Experion
Release 300.1:
• The LIOM function block set.
• CAB related function blocks other than the Custom Data Block (CDB)
• The REEOUT Function Block – an ACE only function block
• Series A IOM function blocks not listed in Table 1 Series A I/O Modules supported
by C300 Controller.
C300 Controller redundancy
The C300 Controller may operate in both non-redundant and redundant configurations.
Redundant operation requires a second identical controller and connecting cables, which
is the typical configuration.
C300 Controller block
When a C300 Controller block is added to the Project tree in Control Builder, a graphic
representation of a controller module and its resident function blocks appears as shown in
Figure 2. The function blocks that are contained in the controller support multiple
execution environments. A Control Execution Environment block (CEEC300) and two
