Configure IOLINK function blocks
To convert a redundant C300 Controller to a non-redundant controller
52 Experion C300 Controller User's Guide R301.1
Honeywell 11/06
Step Action Result
If reusing the controller elsewhere in the
system, see the procedure To install a
C300 Controller.
3
In the Monitor view, right click on the
secondary C300 Controller block.
Choose delete.
The secondary C300 Controller icon
disappears from the tree view.
4
In the Project view, right click on the
primary C300 Controller icon and choose
Module Properties.
Calls up the primary C300 Controller
configuration form.
5
Uncheck the Module is redundant check
box. Click the OK button.
The secondary C300 Controller icon is
deleted from the project view, the non-
redundant C300 Controller icon changes
from a redundant to a non-redundant
icon, and the non-redundant C300 icon
shows a delta
6
Click non-redundant C300 block icon in
Project view. Perform a Load to the
controller.
The delta sign should disappear from the
C300 Controller icon in the Project view.
The C300 Controller icon in the Monitor
view should indicate the controller is now
non-redundant.
Configure IOLINK function blocks
Two IOLINK blocks are created automatically when a C300 Controller function block is
added to the Project tab. These blocks provide the interface to the controller for
associated I/O Module blocks
Prerequisites
• Control Builder is running
• Tree windows are open
Considerations
All illustrations used in the procedure are for example purposes only.
