C300 Controller Block
Hardware Information tab
R301.1 Experion C300 Controller User's Guide 87
11/06 Honeywell
Plain Text Parameter Name
User
Configurable
Notes
Responding to C200s
TNUMCPMOUTCON
No
Shows the number of
originator CPMs (C200
controllers).
Responding to FIM4s
TNUMSCFIMOUTCON
No
Shows the number of
originator Series C FIMs.
Responding to SIM-
C200s
TNUMSCEOUTCON
No
Shows the number of
originator SCEs.
Responding to
LIOIMs
TNUMLIOMOUTCON
No
Shows the number of
originator LIOIMs.
Hardware Information tab
The Hardware Information tab contains data describing the C300 Controller module
device including firmware and hardware revision and version information. The
parameters provided here are used for maintenance, troubleshooting and problem
description purposes. The following table summarizes the parameter data you can view
on the Hardware Information tab of the configuration form for the selected C300
block.
Plain Text Parameter Name
User
Configurable
Notes
Firmware Version
Boot Image Version
BOOTIMAGEVER
No
Shows the current version
of boot firmware installed
in the module.
Application Image
Version
See Note 1
IMAGEVER_D
No
Shows the current version
of application firmware
installed in the module.
Hardware Factory Information
Module Type
MODTYPE
No
Identifies the model
number and identification
string of the module.
Serial Number
SERIALNUM
No
Identifies the serial
number of the module.
