Add an I/O Channel to a Control Module
To assign Series C IO Modules and Process Manager IOMs to IOLINK blocks
R301.1 Experion C300 Controller User's Guide 73
11/06 Honeywell
Step Action Result
6
Click the Close button.
Closes dialog box and assigned
components now appear in IOLINK folder
in Project tab.
Add an I/O Channel to a Control Module
An IO Channel block represents a channel in one of the various IO modules (IOMs). The
IO Channel blocks can be added to a control module in the Project tab to build a process
control strategy.
The procedure is a drag and drop operation and is the same for any type IO Channel,
whether it is an AI channel in a Series C IO module or an DO channel in a Series A IO
module.
Prerequisites
• Control Builder is running
• Tree windows are open
Considerations
All illustrations used in the procedure are for example purposes only.
Blocks appear as Block Symbols on the Control Module chart.
